BW Type Cable Gland
Brass Hex Nuts are durable, corrosion-resistant fasteners commonly used in various industrial and construction applications. Manufactured to DIN 934 standards, these nuts provide secure fastening solutions for bolts and threaded rods. Ideal for environments where resistance to rust and weathering is crucial, brass hex nuts are both reliable and versatile, making them a preferred choice for long-term projects.
For usage with steel wire armoured cables, use the BW Type Cable Gland (H694-XL). used to assure electrical continuity and mechanical retention of the cable by gripping the Armor wire. When a watertight seal is not necessary, the BW gland is employed indoors.
Shrouds, lock nuts, and earth tags are included with the BW and CW glands as standard equipment. Depending on the cable being terminated to, they are both also offered in LSNH (Low Smoke Non Halogen) and regular PVC versions.
BW Gland – Brass gland for use with steel wire armoured cables (H694-XL).Used to provide clamping of the armour wire to ensure electrical continuity and mechanical retention of the cable. The BW gland is used for indoor application when a waterproof seal
is not required.
CW Gland – Brass gland for use with steel wire armoured cables (H694-XL). Used to provide clamping of the armour wire to ensure electrical continuity and
mechanical retention of the cable. The CW type gland is used for outdoor applications and where necessary
to provide an IP66 seal with the outer sheath of the cable.
BW Type Cable Gland Description
Technical Data
Standard : BS 6121
IP RATING : IP30
APPLICATION :Dry Indoor, for use with all types of SWA Cable.
FUNCTION : Provide mechanical Cable Retention & Electrical Wire continuity via Armoured Wire.
Thread : Metric
Operating Temp. : -60°C to +200°C
Cable Type : Single Wire Armour (SWA) Cable
Features : Two Part Armour Lock
Accessories : PVC Shroud, Earth Tag, Galvanized Steel Lock Nut
BW Type Size Description
| GLAND SIZE | THREAD SIZE ‘C’ | MINIMUM LENGTH OF THREAD ‘D’ | CABLE RANGE | ||
| METRIC | NPT | MAX ‘A’ | MAX ‘B’ | ||
BW 20S | M20 | ½” | 10 | 11.50 | 15.50 |
BW 20 | M20 | ½” | 10 | 14.00 | 20.50 |
BW 25 | M25 | 3/4″ | 10 | 20.00 | 27.20 |
BW 32 | M32 | 1″ | 10 | 26.30 | 33.50 |
BW 40 | M40 | 1¼” | 15 | 32.00 | 40.00 |
BW 50S | M50 | 1½” | 15 | 38.20 | 46.30 |
BW 50 | M50 | 2″ | 15 | 44.00 | 52.60 |
BW 63S | M63 | 2″ | 15 | 50.10 | 59.00 |
BW 63 | M63 | 2½” | 15 | 56.00 | 65.30 |
BW 75S | M75 | 2½” | 15 | 62.00 | 71.60 |
BW 75 | M75 | 3″ | 15 | 68.00 | 78.00 |
BW 90 | M90 | 3″ | 20 | 80.50 | 91.00 |
Technical Data
Standard : BS 6121
IP Rating : IP30
Application : Dry Indoor, for use with all types of SWA Cable.
Function : Provide Mechanical Cable Retention Electrical Wire continuity via Armored Wire.
Optional Threads :METRIC,NPT,BSP & PG.
Finish : Natural Brass & Nickel Finish
Operating Temp. : 80° – C to + 600⁰ C.
Accessories : Matching Accessories available like PVC Shroud, Lock Nuts & Earth Tags
Technical Data
Standard : BS 6121
IP Rating : IP30
Application : Dry Indoor, for use with all types of SWA Cable.
Function : Provide Mechanical Cable Retention Electrical Wire continuity via Armored Wire.
Optional Threads :METRIC,NPT,BSP & PG.
Finish : Natural Brass & Nickel Finish
Operating Temp. : 80° – C to + 600⁰ C.
Accessories : Matching Accessories available like PVC Shroud, Lock Nuts & Earth Tags
BW-4 Part Size Description
| GLAND SIZE | THREAD SIZE ‘C’ | MINIMUM LENGTH OF THREAD ‘D’ | CABLE RANGE | ||
| METRIC | NPT | MAX ‘A’ | MAX ‘B’ | ||
BW 20 S | M 20 | ½” | 10 | 11.50 | 15.50 |
BW 20 L | M 20 | ½” | 10 | 14.00 | 20.50 |
BW 25 S | M 25 | 3/4″ | 10 | 18.00 | 24.00 |
BW 25 L | M 25 | 3/4″ | 10 | 20.00 | 27.20 |
BW 32 S | M 32 | 1″ | 10 | 26.30 | 33.50 |
BW 32 L | M 32 | 1″ | 10 | 26.30 | 33.50 |
BW 40 S | M 40 | 1 1/4″ | 13 | 31.50 | 39.50 |
BW 40 L | M 40 | 1 1/4″ | 13 | 32.00 | 40.00 |
BW 50 S | M 50 | 1 1/2″ | 13 | 38.20 | 46.30 |
BW 50 L | M 50 | 2″ | 13 | 44.00 | 52.60 |
BW 63 S | M 63 | 2″ | 14 | 50.10 | 59.00 |
BW 63 L | M 63 | 2½” | 14 | 56.00 | 65.30 |
| BW 75 S | M 75 | 2½” | 15 | 62.00 | 71.60 |
| BW 75 L | M 75 | 3″ | 15 | 68.00 | 78.00 |
| BW 90 S | M 90 | 3″ | 18 | 80.50 | 91.00 |
| BW 90 L | M 90 | 3″ | 18 | 80.50 | 91.00 |
Available in 5-10 days for different items.
CAD / PDF / DWG / IGS / STEP.
Standard package, Carton box or Pallet, As per customized specifications
DHL, FEDEX, UPS and By Sea or as per client’s requirements.
